60～400T
GANTY TYPE SPEED
PRECISION FOUR POSTGUIDER
PRESS MACHINE
With high rigidity design inmachine frame, the machine body is welded by quality steel and treated bytension elimination improve stability and reliability of precision for themachine
Keep the transmissioncenter and machine center in unifrmity guarantee the precision of pressing
高钢性机设计，采用优质钢板焊制，经过消除内应力工艺处理。提高了整机精度的稳定性和可靠性
传动中心舆机器整体的中心一致，确保冲压的精确、稳定
|
机 型
|
Modelodel
|
型号规格
|
APJ-60
|
APJ-80
|
APJ-125
|
APJ-200
|
APJ-220
|
APJ-300
|
APJ-400
|
|
顿 数
|
Capacity
|
ton
|
60
|
80
|
125
|
200
|
220
|
300
|
400
|
|
行 程
|
Stroke
|
mm
|
30
|
30
|
30
|
30
|
30
|
30
|
30-50
|
|
每分钟行程数
|
Strokes per minute
|
s.p.m
|
200-800
|
200-700
|
150-700
|
150-600
|
150-600
|
150-400
|
150-350
|
|
下工作台尺寸
|
Bolster area
|
mm
|
950x650
|
1100x750
|
1200x850
|
1700x950
|
1900x1000
|
2200x1000
|
2700x1200
|
|
下料孔
|
Bolster hole
|
mm
|
700x125
|
800x150
|
1000x200
|
1300x250
|
1400x300
|
2000x300
|
2200x400
|
|
滑块面积
|
Slide
|
mm
|
950x420
|
1100x500
|
1200x600
|
1700x700
|
1900x750
|
2200x900
|
2700x1100
|
|
模高调整行程
|
Die height adjustment
|
mm
|
300-350
|
330-380
|
360-410
|
370-420
|
370-420
|
400-450
|
420-480
|
|
模高调整马达
|
Adjusting motor
|
kw
|
0.4
|
0.75
|
0.75
|
1.5
|
1.5
|
2.2
|
3.7
|
|
送料线高度
|
Linear height
|
mm
|
160
|
175±50
|
195±50
|
200±50
|
200±50
|
210±50
|
220±50
|
|
主电动机
|
Main motor
|
kw
|
19
|
22
|
37
|
45
|
45
|
55
|
75
|
